通达信【主力智绘图】主图指标 抄底逃顶 追踪主力 关键转折与趋势突破！源码
主力智绘图是一款融合多维度分析的专业级指标，基于价格的高低点、趋势强弱、主力资金动向等关键数据，为大家提供清晰的量化图形参考，帮助判断潜在买卖点与趋势切换节点。
主要功能：
关键点标注
自动标记市场的**“前高”和“前低”**，提供市场关键支撑与压力位。
通过“顶”与“底”的动态线，直观呈现市场潜在的转折点。
潜在转折点提示
通过复杂的逻辑算法，精准定位市场可能的反转信号。
标记“★抄底”和“★逃顶”信号，提供决策辅助。
趋势延展分析
根据价格波动计算未来的目标价格区间，显示上涨空间与波段目标，让我们可以提前规划。
形态识别与绘图
自动生成“钳形结构”与“右臂延伸”等经典形态，帮助分析价格运行的合理性。
清晰的区域分布色带，突显主力资金进出迹象。
逻辑解析
高低点计算
通过回溯一定周期的最高价和最低价，确定“前一高”“前二低”等支撑与阻力关键点，动态调整市场运行区间。
趋势突破信号
结合历史高点与低点，分析关键点后的运行趋势，生成“潜在转折点”提示信号。
目标价估算
采用复合算法计算未来的目标价，包括保守目标（ED1）、中等目标（ED2）、进取目标（ED3），并通过文字标注一目了然。
抄底与逃顶策略
利用“ZIG”（折线模型）捕捉短期反弹或下跌的趋势拐点，标记买入与卖出机会。
使用指南
顶部与底部识别
图表中标注的“顶”与“底”线是关键转折点的重要参考，顶部通常为阻力位，底部则是支撑位。
当价格突破“顶”，伴随成交量放大，可视为趋势延续的买入信号。
抄底与逃顶策略
黄色“★抄底”标记表示短期低点，适合激进的老师们试错入场。
白色“★逃顶”标记则提醒可能的短期高点，适合止盈或减仓。
目标价参考
在图表右侧标注了波段目标价和上涨空间，方便大家快速评估潜在收益。
区域形态分析
区域色带直观显示了主力资金运行轨迹，例如黄色和红色表示关键形态，蓝色和灰色展示潜在的市场震荡区。
N:=8;
A1:=REF(HIGH,N)=HHV(HIGH,2*N+1);
B1:=FILTER(A1,N);
C1:=BACKSET(B1,N+1);
D1:=FILTER(C1,N);
A2:=REF(LOW,N)=LLV(LOW,2*N+1);
B2:=FILTER(A2,N);
C2:=BACKSET(B2,N+1);
D2:=FILTER(C2,N);
E1:=(REF(LLV(LOW,2*N),1)+REF(HHV(HIGH,2*N),1))/2;
E2:=(HIGH+LOW)/2;
H1:=(D1 AND NOT(D2 AND E1>=E2)) OR ISLASTBAR OR BARSCOUNT(CLOSE)=1;
L1:=(D2 AND NOT(D1 AND E1<E2));
H2:=(D1 AND NOT(D2 AND E1>=E2));
X1:=REF(BARSLAST(H1),1)+1;F1:=BACKSET(H1 AND COUNT(L1,X1)>0,LLVBARS(IF(L1,LOW,10000),X1));
G1:=F1>REF(F1,1);
I1:=BACKSET(G1,2);
LD:=I1>REF(I1,1);
L2:=LD OR ISLASTBAR OR BARSCOUNT(CLOSE)=1;
X2:=REF(BARSLAST(L2),1)+1;
F2:=BACKSET(L2 AND COUNT(H2,X2)>0,HHVBARS(IF(H2,HIGH,0),X2));
G2:=F2>REF(F2,1);
I2:=BACKSET(G2,2);
HD:=I2>REF(I2,1);
J1:=BACKSET(ISLASTBAR,MIN(BARSLAST(HD),BARSLAST(LD))+1);
J2:=J1>REF(J1,1);
A3:=H<REF(H,REF(BARSLAST(HD),1)+1);
B3:=REF(H,REF(BARSLAST(HD),1)+1)>REF(H,REF(BARSLAST(HD),1)+2+REF(BARSLAST(HD),REF(BARSLAST(HD),1)+2));
D3:=A3 AND B3 AND HD;
E3:=BACKSET(D3,REF(BARSLAST(HD),1)+2);
HH:=E3>REF(E3,1);
A4:=L>REF(L,REF(BARSLAST(LD),1)+1);
B4:=REF(L,REF(BARSLAST(LD),1)+1)<REF(L,REF(BARSLAST(LD),1)+2+REF(BARSLAST(LD),REF(BARSLAST(LD),1)+2));
D4:=A4 AND B4 AND LD;
E4:=BACKSET(D4,REF(BARSLAST(LD),1)+2);
LL:=E4>REF(E4,1);
H3:=HH OR ISLASTBAR OR BARSCOUNT(C)=1;
X3:=REF(BARSLAST(H3),1)+1;
F3:=BACKSET(H3 AND COUNT(LL,X3)>0,LLVBARS(IF(LL,L,POW(10,20)),X3));
G3:=F3>REF(F3,1);
I3:=BACKSET(G3,2);
LZ:=I3>REF(I3,1);
L4:=LZ OR ISLASTBAR OR BARSCOUNT(C)=1;
X4:=REF(BARSLAST(L4),1)+1;
F4:=BACKSET(L4 AND COUNT(HH,X4)>0,HHVBARS(IF(HH,H,-POW(10,20)),X4));
G4:=F4>REF(F4,1);
I4:=BACKSET(G4,2);
HZ:=I4>REF(I4,1);
K1:=BACKSET(ISLASTBAR,MIN(BARSLAST(HZ),BARSLAST(LZ))+1);
K2:=K1>REF(K1,1);
UU:=BACKSET(ISLASTBAR,BARSLAST(LD)+1);
VV:=UU>REF(UU,1);
WW:=BACKSET(VV,REF(BARSLAST(LD),1)+2);
XX:=WW>REF(WW,1);
UU2:=BACKSET(ISLASTBAR,BARSLAST(HD)+1);
VV2:=UU2>REF(UU2,1);
WW2:=BACKSET(VV2,REF(BARSLAST(HD),1)+2);
XX2:=WW2>REF(WW2,1);
YY:=BACKSET(XX,REF(BARSLAST(LD),1)+2);
ZZ:=YY>REF(YY,1);{前三低天数}
YY2:=BACKSET(XX2,REF(BARSLAST(HD),1)+2);
ZZ2:=YY2>REF(YY2,1);{前三高天数}
YY3:=BACKSET(ZZ2,REF(BARSLAST(HD),1)+2);
ZZ3:=YY3>REF(YY3,1);{前四高天数}
前一低:=REF(L,BARSLAST(VV)),COLOR99FF66,DOTLINE,LINETHICK3;
前二低:=REF(L,BARSLAST(XX)),COLORFF66FF,POINTDOT,LINETHICK3;
前三低:=REF(L,BARSLAST(ZZ)),COLOR99FF66,POINTDOT,LINETHICK3;
前一高:=REF(H,BARSLAST(VV2)),COLOR99FF66,POINTDOT,LINETHICK3;
前二高:=REF(H,BARSLAST(XX2)),COLORFF66FF,POINTDOT,LINETHICK3;
前三高:=REF(H,BARSLAST(ZZ2)),COLOR99FF66,POINTDOT,LINETHICK3;
底:=REF(L,BARSLAST(VV)),COLORRED,LINETHICK2;
顶:=REF(H,BARSLAST(VV2)),COLORGREEN,LINETHICK2;
DQD1:=CONST(BARSLAST(VV));
DQD2:=CONST(BARSLAST(XX));
DQD3:=CONST(BARSLAST(ZZ));
DQH1:=CONST(BARSLAST(VV2));
DQH2:=CONST(BARSLAST(XX2));
DQH3:=CONST(BARSLAST(ZZ2));
HQD1:=REF(L,BARSLAST(VV));
HQD2:=REF(L,BARSLAST(XX));
HQD3:=REF(L,BARSLAST(ZZ));
HQH1:=REF(H,BARSLAST(VV2));
HQH2:=REF(H,BARSLAST(XX2));
HQH3:=REF(H,BARSLAST(ZZ2));
XXA1:=STRCAT('X:',CON2STR(HQD3,2));
DRAWTEXT(CURRBARSCOUNT=CONST(DQD3)+1,CONST(HQD3)*0.99,XXA1),COLORYELLOW;
C3:顶+(顶-底)*1,DOTLINE,COLORWHITE;
TG:IF(C>顶,顶+(顶-底)*1,DRAWNULL),DOTLINE,COLORWHITE;
DRAWTEXT(CURRBARSCOUNT=CONST(BARSLAST(VV))+1,C3,'TG(C3)'),COLORYELLOW;
DRAWTEXT(CURRBARSCOUNT=CONST(BARSLAST(VV2))+1,C3,'TG(C3)'),COLORYELLOW;
字:=STRCAT(STRCAT(STRCAT('【',STKNAME),'】 '),HYBLOCK);
DRAWTEXT_FIX(ISLASTBAR,0.2,0.09,0,字),COLORYELLOW;
DRAWTEXT_FIX(ISLASTBAR,0.2,0.01,0,'【D为潜在转折点】'),COLORRED;
DRAWTEXT_FIX(ISLASTBAR AND C<C3,0.2,0.24,0,STRCAT('【上涨空间】',STRCAT(CON2STR(100*(C3-C)/C,2),'%'))),COLORYELLOW;
DRAWTEXT_FIX(ISLASTBAR,0.2,0.16,0,STRCAT('【波段目标】',STRCAT(CON2STR(C3,2),'元'))),COLORMAGENTA;
DRAWTEXT_FIX(ISLASTBAR AND C>C3,0.2,0.30,0,STRCAT('【目标实现】','清仓')),COLORYELLOW;
QD1:=REF(L,BARSLAST(VV)),COLOR99FF66,POINTDOT,LINETHICK3;
QD2:=REF(L,BARSLAST(XX)),COLORFF66FF,POINTDOT,LINETHICK3;
QH1:=REF(H,BARSLAST(VV2)),COLOR99FF66,POINTDOT,LINETHICK3;
QH2:=REF(H,BARSLAST(XX2)),COLORFF66FF,POINTDOT,LINETHICK3;
{DRAWLINE(VV2,H,VV,QH1,0),COLORMAGENTA,LINETHICK3;}
{DRAWLINE(XX,QD2,XX2,QH2,0),COLORRED,LINETHICK3;}
KGCS:=IF(CONST(BARSLAST(VV))>CONST(BARSLAST(VV2)),1,-1),NODRAW;
GDTS:IF(KGCS>0,CONST(BARSLAST(XX2)),CONST(BARSLAST(VV2))),NODRAW;
DDTS:CONST(BARSLAST(XX)),NODRAW;
GDH:REF(H,GDTS),NODRAW;
DDL:REF(L,DDTS),NODRAW;
TJ1:=IF(GDH>DDL,1,0);
右侧右臂膀:DRAWLINE(CURRBARSCOUNT=DDTS+1,L,CURRBARSCOUNT=GDTS+1,H,0),LINETHICK2,COLORRED;
DRAWLINE(CURRBARSCOUNT=GDTS+1,H,ISLASTBAR,CONST(GDH),0),DOTLINE,COLORMAGENTA;
MIMA:=CONST(SQRT(GDH/DDL));
ED1:=CONST(GDH/MIMA);
ED2:=CONST(GDH/SQRT(MIMA));
ED3:=CONST(GDH/(SQRT(MIMA)+MIMA-1));
NEWH:CONST(DDL*(POW(SQRT(GDH/DDL),2)*2-1)),NODRAW;
NEWH11:=CONST(DDL*(POW(SQRT(SQRT(GDH/DDL)),2)*2-1)),NODRAW;
NEWH12:=CONST(DDL*(POW((SQRT(GDH/DDL)+SQRT(SQRT(GDH/DDL))-1),2)*2-1)),NODRAW;
均值:=(NEWH11+NEWH12+NEWH*4)/6;
标准差:=(NEWH11-NEWH12)/6;
NEWH1:=NEWH+标准差;
NEWH2:=NEWH-标准差;
STICKLINE(CURRBARSCOUNT=GDTS+1,CONST(GDH),CONST(ED3),0,-1),COLORMAGENTA;
LLOW:FINDLOW(L,0,GDTS,1),NODRAW;
DLLOW:=FINDLOWBARS(L,0,GDTS,1),NODRAW;
DRAWLINE(CURRBARSCOUNT=GDTS+1,H,CURRBARSCOUNT=CONST(DLLOW)+1,L,0),DOTLINE,COLORMAGENTA;
DSHIGH:FINDHIGHBARS(H,0,DLLOW,1),NODRAW;
ZDHIGH:FINDHIGH(H,0,DLLOW,1),NODRAW;
CCC1:=STRCAT('C2:',CON2STR(CONST(ED1),2));
CCC2:=STRCAT('C1:',CON2STR(CONST(ED2),2));
CCC3:=STRCAT('C3:',CON2STR(CONST(ED3),2));
DD1:=STRCAT('E1:',CON2STR(CONST(NEWH2),2));
DD2:=STRCAT('E2:',CON2STR(CONST(NEWH),2));
DD3:=STRCAT('E3:',CON2STR(CONST(NEWH1),2));
DRAWLINE(CURRBARSCOUNT=GDTS+1,H,CURRBARSCOUNT=CONST(DLLOW)+1,L,0),DOTLINE,COLORMAGENTA;
STICKLINE(CURRBARSCOUNT=CONST(DLLOW)+1,CONST(LLOW),CONST(NEWH2),0,-1),COLORRED;
DRAWLINE(CURRBARSCOUNT=CONST(DQD3)+1,CONST(HQD3),CURRBARSCOUNT=CONST(DQD1)+1,L,0),DOTLINE,COLORGRAY;
GDCS:=IF(CONST(BARSLAST(ZZ2))>CONST(BARSLAST(ZZ)),1,0);
{造型}
大头顶:IF(GDCS=1,DRAWLINE(XX2,H,CURRBARSCOUNT=GDTS+1,H,0),DRAWNULL),COLORGRAY,DOTLINE;{前三高接前一高}
头顶:IF(NOT(GDCS=1),DRAWLINE(ZZ2,H,CURRBARSCOUNT=GDTS+1,H,0),DRAWNULL),COLORGRAY,DOTLINE;{前三高接前一高}
左大钳子:IF(GDCS=1,DRAWLINE(ZZ2,H,ZZ,L,0),DRAWNULL),COLORYELLOW,LINETHICK3;{前三高接前三低}
左侧左头部:=IF(GDCS=1,DRAWLINE(ZZ,L,XX2,H,0),DRAWNULL),COLORMAGENTA,LINETHICK3;{前三低对接前二高}
左侧右头部:=IF(GDCS=1,DRAWLINE(XX2,H,XX,L,0),DRAWNULL),COLORMAGENTA,LINETHICK3;{前三低对接前二高}
左侧底部:=IF(GDCS=1,DRAWLINE(ZZ,L,XX,L,0),DRAWNULL),COLORMAGENTA,LINETHICK1;{前三低对接前二高}
右侧右头部:=IF(GDCS=1,DRAWLINE(VV2,H,VV,L,0),DRAWNULL),COLORMAGENTA,LINETHICK3;{前三低对接前二高}
右侧左头部:=IF(GDCS=1,DRAWLINE(XX,L,VV2,H,0),DRAWNULL),COLORMAGENTA,LINETHICK3;{前三低对接前二高}
右侧底部:=IF(GDCS=1,DRAWLINE(XX,L,VV,L,0),DRAWNULL),COLORMAGENTA,LINETHICK1;{前三低对接前二高}
右大钳子:IF(GDCS=1,DRAWLINE(CURRBARSCOUNT=CONST(DLLOW)+1,CONST(LLOW),CURRBARSCOUNT=CONST(DSHIGH)+1,CONST(ZDHIGH),0),DRAWNULL),COLORYELLOW,LINETHICK3;
左侧左头:=IF(NOT(GDCS=1),DRAWLINE(ZZ,L,ZZ2,H,0),DRAWNULL),COLORYELLOW,LINETHICK3;{前三低接前三高}
左侧右头:=IF(NOT(GDCS=1),DRAWLINE(ZZ2,H,XX,L,0),DRAWNULL),COLORYELLOW,LINETHICK3;{前三高接前二低}
左底部:=IF(NOT(GDCS=1),DRAWLINE(ZZ,L,XX,L,0),DRAWNULL),COLORGRAY,DOTLINE;{前三低接前二低}
右底部:=IF(NOT(GDCS=1),DRAWLINE(XX,L,CURRBARSCOUNT=CONST(DLLOW)+1,CONST(LLOW),0),DRAWNULL),COLORWHITE,DOTLINE;{前三低接前二低}
右侧左头:=IF(NOT(GDCS=1),DRAWLINE(XX,L,XX2,H,0),DRAWNULL),COLORWHITE,LINETHICK3;{前三低接前二低}
右侧右头:=IF(NOT(GDCS=1),DRAWLINE(XX2,H,CURRBARSCOUNT=CONST(DLLOW)+1,CONST(LLOW),0),DRAWNULL),COLORWHITE,LINETHICK3;{前三低接前二低}
右钳子:IF(NOT(GDCS=1),DRAWLINE(CURRBARSCOUNT=CONST(DLLOW)+1,CONST(LLOW),CURRBARSCOUNT=CONST(DSHIGH)+1,CONST(ZDHIGH),0),DRAWNULL),COLORYELLOW,LINETHICK3;
左钳子:IF(NOT(GDCS=1),DRAWLINE(ZZ3,H,ZZ,L,0),DRAWNULL),COLORYELLOW,LINETHICK3;
{造型}
DRAWBAND(左侧左头部,RGB(250,0,0),左侧底部,RGB(0,0,0));
DRAWBAND(左侧右头部,RGB(0,68,88),左侧底部,RGB(0,0,0));
DRAWBAND(右侧左头部,RGB(250,0,0),右侧底部,RGB(0,0,0));
DRAWBAND(右侧右头部,RGB(0,68,88),右侧底部,RGB(0,0,0));
{造型}
DRAWBAND(左侧左头,RGB(250,0,0),左底部,RGB(0,0,0));
DRAWBAND(左侧右头,RGB(0,68,88),左底部,RGB(0,0,0));
DRAWBAND(右侧左头,RGB(250,0,0),右底部,RGB(0,0,0));
DRAWBAND(右侧右头,RGB(0,68,88),右底部,RGB(0,0,0));
XXA3:=STRCAT('A:',CON2STR(前二高,2));
DRAWTEXT((CURRBARSCOUNT=CONST(BARSLAST(XX2))+1)*CONST(GDCS),CONST(前二高)*1.01,XXA3);
XXA2:=STRCAT('A:',CON2STR(前二高,2));
FXCS1:=CONST(BARSLAST(XX2))>CONST(BARSLAST(XX));{前二高大于前二低天数}
DRAWTEXT((CURRBARSCOUNT=CONST(BARSLAST(XX2))+1)*CONST(FXCS1),CONST(HQH2)*1.01,STRCAT('A:',CON2STR(HQH2,2))),COLORYELLOW;
FXCS2:=CONST(BARSLAST(XX2))<CONST(BARSLAST(XX));{前二高小于前二低天数}
DRAWTEXT((CURRBARSCOUNT=CONST(BARSLAST(ZZ2))+1)*CONST(FXCS2),CONST(HQH3)*1.01,STRCAT('A:',CON2STR(HQH3,2))),COLORYELLOW;
DDD1:=CONST(GDH)*CONST(LLOW)/CONST(DDL);
DDD2:=CONST(HQH2)*CONST(LLOW)/CONST(DDL);
DRAWTEXT_FIX(ISLASTBAR,0.2,0.5,0,STRCAT('【右爪目标】',STRCAT(CON2STR(DDD1,2),'元'))),COLORGREEN;
DRAWTEXT_FIX(ISLASTBAR,0.2,0.6,0,STRCAT('【右爪目标】',STRCAT(CON2STR(DDD2,2),'元'))),COLORYELLOW;
AA1:=STRCAT('B:',CON2STR(CONST(DDL),2));
BB1:=STRCAT('C:',CON2STR(CONST(GDH),2));
DRAWTEXT(CURRBARSCOUNT=GDTS+1,CONST(GDH)*1.01,BB1);
DRAWTEXT(CURRBARSCOUNT=DDTS+1,CONST(DDL)*0.99,AA1);
DRAWTEXT(CURRBARSCOUNT=GDTS+1,ED1,CCC1);
DRAWTEXT(CURRBARSCOUNT=GDTS+1,ED2,CCC2);
DRAWTEXT(CURRBARSCOUNT=GDTS+1,ED3,CCC3);
DRAWTEXT(CURRBARSCOUNT=CONST(DLLOW)+1,CONST(NEWH2),DD1);
DRAWTEXT(CURRBARSCOUNT=CONST(DLLOW)+1,CONST(NEWH),DD2);
DRAWTEXT(CURRBARSCOUNT=CONST(DLLOW)+1,CONST(NEWH1),DD3);
CC1:=STRCAT('D:',CON2STR(CONST(LLOW),2));
DRAWTEXT(CURRBARSCOUNT=CONST(DLLOW)+1,CONST(LLOW)*0.99,CC1),COLORRED;
DRAWLINE(CURRBARSCOUNT=GDTS+1,ED1,CURRBARSCOUNT=CONST(DLLOW)+1,ED1,0),DOTLINE,COLORMAGENTA;
DRAWLINE(CURRBARSCOUNT=GDTS+1,ED2,CURRBARSCOUNT=CONST(DLLOW)+1,ED2,0),DOTLINE,COLORMAGENTA;
DRAWLINE(CURRBARSCOUNT=GDTS+1,ED3,CURRBARSCOUNT=CONST(DLLOW)+1,ED3,0),DOTLINE,COLORMAGENTA;
STICKLINE(CURRBARSCOUNT=CONST(DLLOW)+1,CONST(LLOW),CONST(NEWH2),0,-1),COLORRED;
DRAWLINE(CURRBARSCOUNT=CONST(DLLOW)+1,CONST(LLOW),CURRBARSCOUNT=CONST(DSHIGH)+1,CONST(ZDHIGH),0),DOTLINE,COLORRED;
DRAWLINE(CURRBARSCOUNT=CONST(DLLOW)+1,CONST(NEWH),CURRBARSCOUNT=CONST(DSHIGH)+1,CONST(NEWH),0),DOTLINE,COLORRED;
DRAWLINE(CURRBARSCOUNT=CONST(DLLOW)+1,CONST(NEWH1),CURRBARSCOUNT=CONST(DSHIGH)+1,CONST(NEWH1),0),DOTLINE,COLORRED;
DRAWLINE(CURRBARSCOUNT=CONST(DLLOW)+1,CONST(NEWH2),CURRBARSCOUNT=CONST(DSHIGH)+1,CONST(NEWH2),0),DOTLINE,COLORRED;
DRAWKLINE(H,O,L,C);
DRAWTEXT(CROSS(ZIG(3,8),REF(ZIG(3,8),1)),LOW*0.978,'★抄底') ,LINETHICK2,COLORYELLOW;
DRAWTEXT(CROSS(REF(ZIG(3,8),1),ZIG(3,8)),HIGH*1.042,'★逃顶') ,LINETHICK2,COLORWHITE;
